1. Substrate
Clean, dry metal. Repair and prime where corrosion is the first risk.
ST-C-COLD
Water-based mid-coat for chilled pipe, refrigerant lines and cold tanks where condensation and heat gain are the duty.
Cold-insulation coating family. Condensation control is a system result (thickness + climate + finish), not a standalone guarantee.
| Property | Typical figure | Note |
|---|---|---|
| Colour | White, tintable | Topcoat carries colour if specified |
| Density | 0.55 ± 0.02 g/cm³ | As stated on the family card |
| Service range | −40 to 150 °C | Long-term as stated |
| Thermal conductivity | ≤ 0.040 W/(m·K) | Typical as stated for this family |
| Bonding | ≥ 4A | As stated on the family card |
| Waterproof rating | < 5 as stated | Family card |
| Fire performance | B2 / B1 as stated | Coating film |
| VOC | ≤ 100 g/L | As supplied — different cap from ST-C-HOT |
| Recommended mid-coat | 2–8 mm dry | Primer < 0.5 mm · topcoat < 0.5 mm |
| Application | Airless spray or blade | Substrate clean and dry; 5–80 °C; RH preferably ≤ 85 % |
Values on this page are typical figures as stated for this family. They are not SHINETON-guaranteed field results. Specify only from the current Technical Data Sheet for the supplied grade.
Operating conditions, acceptance criteria and system design stay with the buyer’s engineer. SHINETON matches the grade, issues documents and agrees inspection and shipment scope.
Clean, dry metal. Repair and prime where corrosion is the first risk.
ST-C-COLD to the dry thickness calculated for the climate.
Weatherable topcoat on outdoor lines and tanks.
